The Osburn 2000 Wood Insert with Heat Activated Variable Speed Blower is the perfect solution for homeowners seeking reliable warmth, efficiency, and a touch of style. This non-catalytic wood insert is EPA 2020 certified, ensuring it meets modern standards for clean and eco-friendly heating. Capable of handling logs up to 20 inches, it’s designed for easy use while providing long-lasting heat. The large ceramic glass door not only adds a sleek look but also offers a clear view of the flames, enhancing the cozy ambiance of your home.
This wood insert delivers impressive heating power with a maximum output of 75,000 BTU/h, efficiently warming spaces between 500 to 2,100 square feet. Its premium 120 CFM blower ensures optimal heat distribution, while the refractory brick-lined firebox improves heat retention. For added convenience, the stainless-steel secondary-air system boosts combustion efficiency, ensuring longer burns and lower emissions. Plus, the glass air-wash system keeps the viewing window clean, so you can always enjoy the beauty of the fire.
Safety and durability are top priorities with the Osburn 2000. Built with a rugged steel body and a cast-iron door frame, it complies with stringent safety standards in both the U.S. and Canada. Whether you’re looking for a heating solution that’s environmentally conscious, powerful, or simply stylish, this wood insert provides a perfect blend of performance and aesthetics, making it an ideal upgrade for any home.
Required to complete the woodstove:
- Faceplate
- Faceplate Trim
- Door Overlay
Specifications
| Combustion technology: | Non-catalytic |
| High-efficiency certified appliance: | Yes, EPA 2020 approved |
| Maximum log length: | 20″ |
| Log positioning: | Over width |
| Chimney diameter: | 6″ |
| Type of chimney: | Liner – ULC-S635, CAN/ULC-S640, UL1777 |
| Baffle type: | C-Cast |
| Approved for a mobile home installation: | No |
| Shipping Weight: | 407 lb (185 kg) |
| Door type: | Single, glass with cast iron frame |
| Glass type: | Ceramic glass |
| Glass surface – dimensions (Width X Height): | 17 1/8″ X 10 1/4″ |
| Glass air-wash system: | Yes |
| Premium quality blower included (CFM): | 120 |
| Overall dimension (Height): | 23 1/8″ |
| Overall dimension (Width): | 28 3/8″ |
| Overall dimension (Depth): | 26 3/8″ |
| Door opening – dimension (Height): | 9″ |
| Door opening – dimension (Width): | 17 1/2″ |
| Firebox – dimension (Height): | 11 7/8″ |
| Firebox – dimension (Width): | 21″ |
| Firebox – dimension (Depth): | 16 3/4″ |
| Firebox lined with refractory bricks for better heat distribution: | Yes |
| Stainless-steel secondary-air system improving gas combustion: | Yes |
| Adjustable threaded legs: | Yes |
| Steel thickness – body: | 3/16″ |
| Steel thickness – top: | 5/16″ |
| Fireplace opening – minimum (Height): | 23 3/8″ |
| Fireplace opening – minimum (Width): | 28 7/8″ |
| Fireplace opening – minimum (Depth): | 15 3/4″ |
| USA standard (emissions): | Comply with EPA 2020 |
| Canadian Standard (emissions): | CSA B415.1-10 |
| USA standard (safety): | UL 1482, UL 737 |
| Canadian standard (safety): | ULC S628 |
| Tested and listed as per applicable standards: | By an accredited laboratory (CAN/USA) |
| Warranty: | Limited lifetime |
Minimum clearances to combustibles*
(Data expressed in inches. 1 inch = 25.4 mm)
Technical Drawings:


Downloads:
About The Manufacturer:

Osburn is a North American manufacturer of quality wood and pellet heating
appliances, that was founded in 1979. The company mainly specializes in wood stoves, pellet stoves, wood fireplaces, wood inserts, and their related accessories. Osburn is widely known for the high-efficiency and performance of its products, for those looking to replace their traditional fireplaces with more sophisticated wood and pellet heating systems for their homes. The company also stocks up on Osburn gas fireplace parts and maintenance products.
